Peterson BTR90 Blower Trailer

Overview

The BTR90 Blower Trailer features the same high capacity delivery system as our popular blower trucks, but with more advantages from a self-contained power unit.

Gain more available system power through a directly linked engine and blower
Cut operational costs over a dedicated truck by moving the BTR with a tractor.

The feed system is designed to yield several advantages:

These benefits plus the lightweight aluminum construction, which yields increased payload capacity, make the BTR90 Blower Trailer a smart investment for your landscape business.

Applications

Mulch

Organic mulch is a product that can decompose, providing nutrients to the soil over time. It can be made from a variety of materials, typically organic, but not exclusively.
Learn More
Playground Chips

Playground chips/mulch typically have a fibrous consistency, free of twigs, leaves and hazardous materials, no larger than two inches long and have the ability to drain water.
Learn More
Compost

Compost is decomposed organic matter derived from either a single source material or blended for specific application performance. Materials can include garden debris, kitchen scraps, manure or yard and lawn waste.
Learn More

Downloads

Blower Truck Brochure
Download (pdf) 7 MB
BTR Blower Trailer Spec Sheet
Download (pdf) 144 KB

Key Specifications

Dimensions	Specifications
Operating Length	1463 cm
Operating Width	259 cm
Operating Height	411 cm
Loading Height	396 cm
Box Length	1173 cm
Box Height	274 cm
Box Volume, Struck	69 m³
Axle Spacing	124 cm
Tool Box	152 cm
5th Wheel Height	122 cm
Front to 5th Wheel	46 cm
5th Wheel Clearance Radius	162 cm
Center Axle to Bumper	137 cm

Dimensions	Specifications
Operating Length	48'
Operating Width	8' 6"
Operating Height	13' 6"
Loading Height	13'
Box Length	38’ 6"
Box Height	9’
Box Volume, Struck	90 yds³
Axle Spacing	49"
Tool Box	60" wide
5th Wheel Height	4'
Front to 5th Wheel	18"
5th Wheel Clearance Radius	64"
Center Axle to Bumper	54"

Weight
Weight with Typical Options	12 700 kg
GCVW
2 axle GCVW	35 244 kg
2 axle Payload	14 877 kg
3 axle GCVW	39 008 kg
3 axle Payload	18 143 kg

Weight
Weight with Typical Options	28,000 lbs
GCVW
2 axle GCVW	77,700 lbs
2 axle Payload	32,800 lbs
3 axle GCVW	86,000 lbs
3 axle Payload	40,000 lbs

Suspension	Specifications
Standard Suspension	Air Ride/Fixed/Tandem
Optional Suspensions	Air Ride/Fixed/Tridem, Air Ride/Slider/Tandem or Tridem
Axle Lim	11 340 kg each
Wheels	22.5 x 8.25 Polished Aluminum
Tires	11R22.5

Suspension	Specifications
Standard Suspension	Air Ride/Fixed/Tandem
Optional Suspensions	Air Ride/Fixed/Tridem, Air Ride/Slider/Tandem or Tridem
Axle Limit	11 340 kg each
Wheels	22.5 x 8.25 Polished Aluminum
Tires	11R22.5

Powertrain	Specifications
Engine	Cat C7.1 Tier IV 168 kW
Fuel Tank Capacity	568 L
Hydraulic Tank Capacity	322 L
Water (Dust Suppression) Option	575 L

Powertrain	Specifications
Engine	Cat C7.1 Tier IV 225 hp
Fuel Tank Capacity	150 gal
Hydraulic Tank Capacity	85 gal
Water (Dust Suppression) Option	200 gal

System Controls
Peterson Adaptive Feed System	Checkmark
Radio Remote	Checkmark

System Controls
Peterson Adaptive Feed System	Checkmark
Radio Remote	Checkmark

Feed System
Floor	Aluminum Walking Floor
Wear Liners	Aluminum
Blower System
Blower	Tri-Lobe^®
Blowing Pressure	1.03 bar
Large Capacity Silencer	Intake and Discharge

Feed System
Floor	Aluminum Walking Floor
Wear Liners	Aluminum
Blower System
Blower	Tri-Lobe^®
Blowing Pressure	15 psi
Large Capacity Silencer	Intake and Discharge

Discharge System
Hose Reel	powered, holds up to 98 m
Discharge Hose Length	6 m heavy-duty, 91 m standard
Hose Diameter	127 mm, 100 mm
Noise Level with Optional Discharge Silencers	87 db at 7 m

Discharge System
Hose Reel	powered, holds up to 320 ft
Discharge Hose Length	20 ft heavy-duty, 300 ft standard
Hose Diameter	5", 4"
Noise Level with Optional Discharge Silencers	87 db at 23‘

Production
Discharge Volume	up to 46 m³ per hour
Material Weight	up to 1245 kg/m³

Actual output may vary due to moisture content, material density and size, support equipment, terrain variables, and hose diameter'

Production
Discharge Volume	up to 60 yds³
Material Weight	up to 2,100 lbs/yd³

Actual output may vary due to moisture content, material density and size, support equipment, terrain variables, and hose diameter'

UNITS:

All specifications subject to change without notice.

Features

Easy Maintenance

A series of drive chains keep the auger and tines moving steadily. Bolt on tensioners and centralized greasing provide easy maintenance.
High Capacity Blower

Our high capacity Tri-Lobe blower provides increased airflow and production. Larger five-inch diameter hoses can blow materials that could plug smaller hoses.
Air Stream Injection System

Evenly distribute seeds or fertilizer directly into the material mix. A tackifier can be added for efficient erosion control applications.
